JBL Packaged 8" 2-Way PA with Powered 8-Channel Mixer and Bluetooth® - EON208P

SPECIFICATION




Specifications

System TypePortable 2-way full-range loudspeakers with powered mixer
Maximum SPL Output121 dB peak
Frequency Range (-10 dB)60 Hz - 20 kHz
Frequency Response (+/-3 dB)70 Hz - 18 kHz
AC Input100-120 V, 220-240 V 50/60 Hz
Amp DesignClass D
System Power Rating300 W (2x 150 W stereo)
Output Connector2 x 1/4" TS (unbalanced) amplifier outputs
Channels1-4: XLR/1/4" jack combo connectors
5-6: one pair of 1/4" balanced TRS jacks (stereo), and one pair of RCA jacks (stereo)
7-8: one pair of 1/4" balanced TRS jacks (stereo), and a 3.5mm stereo jack
Phantom PowerCH1 and CH2 have phantom power control and share the same selection switch
Hi-Z SelectionCH3 has a Hi-Z selection switch used for guitar signal input
Mixer Output ConnectorsMonitor Out: one pair of RCA jacks (stereo), and one pair of 1/4" balanced TRS jacks (stereo)
Headphone Out: 3.5mm stereo jack
Subwoofer Out: 1/4" balanced TRS jack
Treble/Bass EQPer-channel high- and low-shelf filters; +/- 12dB cut and boost
System LimiterOn-board DSP limiting
LF Driver1x JBL 8" (203mm) woofer
HF Driver1x 1" Neodymuim black aluminum dome tweeter
Coverage Pattern100° horizontal x 60° vertical
Crossover Frequency2 kHz
Crossover Type2-way passive network, 2nd order filters (12dB cutoff per octave)
EnclosurePolypropylene
Suspension/Mounting36 mm pole socket
HandlesOne on top
Speaker GrillePowder-coated perforated steel
Shipping Package(HxWxD)22.6" (575 mm) x 30.5" (775 mm) x 15.7" (400 mm)
Net Weight38.8 lbs (17.6 kg)
  • Product Code: EON208P
  • Availability: In Stock
  • Rs.118,750
  • Price in reward points: 100
This product has a minimum quantity of 10
